(DC-DC step down converter ) LM2596HVS module PCB 60V 50V 48V 42V 40V 38V 36V 24V to 5V 12V 24V 28V step down voltage regulator

!! If you order more than 100pcs, PLZ contact me to get a better price and freight.

1, volume length 45* width 24* high 11mm (containing potentiometer)

Input: IN+ positive input level, the IN- input cathode

Output mode: OUT+ output, OUT- output negative pole

1, the input voltage: 4.5-60V (Note: the above 50V could not work for a long time)

Control mode: to correct the input power (4.5-60V) multimeter and then monitor the output voltage and potentiometers (general clockwise turn boost, inverse to buck),

Output voltage: (3-35V) continuously adjustable (suggest no-load debugging).

The dropout voltage: 1.5V

Output current: rated current is 2A, the maximum 3A

The maximum output power: 15W

The highest conversion efficiency: 92% (the higher the voltage, the higher the efficiency)

The static power consumption is only about 6mA.

Connection: welding, and the pin can be directly welded on PCB.

Working temperature: industrial grade (-40  to +85)

Load regulation: + 1%

Voltage regulation rate: ± 0.5% (in order to achieve a no-load output voltage will be higher, but as long as there is with 1MA load, the output voltage is normal, does not affect the function, please rest assured that use.)

Short circuit protection: current limit, over temperature protection, self recovery.

Advantage: choose to use double-sided thick high quality black oil PCB board, all of the use of imported aluminum electrolytic capacitors, high Q value and high power inductors. In addition each plate through rigorous testing, all detected anti electrostatic protection bag packaging using independent.

-----------------------------------------------------------------------------------------------------------------
